Name: Coats 4TV21NSR1 10,000 lb 2N1 2 Post Lift (Red)
Brand: Coats
SKU: 4TV21NSR1
Price: 7999 USD
Availability: InStock

Coats 4TV21NSR1 10,000 lb 2N1 2 Post Lift (Red)

2N1 Arm: Easy access to approved lift points with 3 piece offset front & rear lifting arms for asymmetric and symmetric loading with reinforced carriage arm pin holes and plated gear style arm restraints.
Non Fatigue Cables & Pulleys: 3/8″ Non Fatigue Cables with 3.5″ Pulleys makes the lift last longer with less maintenance.
Tube Column Reinforcement: The 2.5” x 1.5” inner tube support lets heavier columns flex less under load.
Adaptable and Flexible: field adjustable height settings and EV compatibility means lower installation cost and greater flexibility.

	Model	10K 2N1
	Capacity	10,000 lb/4.5 T
	ALI Certification	Yes
A	Overall Height	148” (3,759 mm)
A	Extended Height	172” (4,369 mm)
B	Overall Width	135 1/2” (3,441 mm)
C	Width Between Columns	112 3/4” (2,864 mm)
D	Drive Thru Width	92” (2,337 mm)
E	Under Bar Clearance	141” (3,581 mm)
F	Lowered Height (standard pad fully in)	4” (102 mm)
G	Raised Height (standard pad fully out)	78” (1,981 mm)
H	Raised Height (with extensions)	87” (2,210 mm)
I	Front Arm Reach	18”- 44” (457 mm-1,118 mm)
J	Rear Arm Reach	33”- 62” (838 mm-1,575 mm)
	Lifting Time	55 seconds
	Standard Power Requirements	230V, 1PH, 60Hz, 20A
