Bendpak PL-12000DP 12K Capacity Parking Lift
12,000 Lb. Cap. Parking Lift / Tandem / Independent Platforms / SPECIAL ORDER
PL-12000DP BendPak’s newest PL-12000DP tall-rise parking lift delivers revolutionary vehicle storage solutions for those challenged with owning more cars and trucks than parking spaces to store them. This lift can greatly expand the number of cars in a facility without expanding building space. As the costs of commercial and residential development increase, gaining additional parking spaces in the same usable space provides instant value. These mechanical parking systems are designed to increase parking density and cut costs over traditional parking methods.
Features
- Dual hydraulic cylinders with heavy-duty galvanized lifting cables.
- Multiple locks for multi-height parked settings.
- Wide baseplates for maximum stability.
- Dual electric-hydraulic power units.
- Heavy-duty steel construction.
- Front and rear wheel chocks.
- 6,000 lb. capacity per side.
- Built-in wheel stops.
- High-speed lifting.
- Tall rise, extended length model - PL-12000DP.
- Perfect for cars, light trucks, motorcycles, and ATVs.
- Superstructure features durable powder-coat finish.
- Full-width platforms to keep bottom vehicles protected.
- Lightweight, extended aluminum approach ramps can be easily stowed.
Specifications
| Style |
Multi-Platform Parking Lift
|
| Number of Platforms | 2 |
| Load Capacity per Platform | 6000 lb |
| Max Rise | 82 in |
| Max Lifting Height | 86.75 in |
| Locking Positions | 6 |
| Locking Spacing | 4.25 in |
| Lock Release | Air Powered Release |
| Lifting Time | 60 seconds |
| Width | 221.25 in |
| Length | 242.75 in |
| Height | 130.5 in |
| Outside Length | 198 in |
| Drive-Thru Width | 85 in |
| Drive-Thru Height | 80.5 in |
| Inside Columns | 100.25 in |
| Runway Width | 19 in |
| Runway Length | 183 in |
| Runway Height | 4.75 in |
| Width Between Runways | 35 - 41 in |
| Outside Edge of Runways | 76 - 82 in |
| Voltage | 208-240V / 50/60 Hz / 1-Phase |
| Amperage | 22 Amps |
| Sound Level | 52 dB |
| Shipping Dimensions | 47 x 189 x 28 in |
| Shipping Weight | 4772 lb |
| Shipping Method | Flatbed |
| Offload Requirement | Forklift |
*Specifications subject to change without notice.
1. Each Platform consists of one Powerside and one Offside Runway and the two optional Aluminum Decks between them.
2. Total Width is defined as the dimensions outside-to-outside of the Baseplates.
3. Special voltages available upon request.
