Coats 4T220SSR1 20,000 lb 2 Post Lift Symmetric - Standard Height (Red)

Coats 4T220SSR1 20,000 lb 2 Post Lift Symmetric - Standard Height (Red)

Features

• Convenient Adapters: Use the screw in saddle adapters with a 5” pad height for light and medium trucks to reduce vehicle set up time.
• Non Fatigue Cables & Pulleys: 3/8″ Non Fatigue Cables with 3.5″ Pulleys makes the lift last longer with less maintenance.
• Sturdier Lift: The self activating arm restraints last longer with less sag and lower maintenance cost.
• Easy Operation: The power unit can be installed on either side. An air release mechanical locking system with stainless steel air cylinders includes a built-in air regulator.

Specifications

Model  20K Symmetric  Capacity  20,000 lb/9 T  ALI Certification  Yes  Lifting Arms  2 Piece Symmetric A  Overall Height  199 1/2” (5,067 mm) B  Overall Width  152” (3,861 mm) C  Width Between Columns  120 1/2” (3,061 mm) D  Drive Thru Width  106 1/2” (2,711 mm) E  Under Bar Clearance  192 1/2” 4,890 mm) F  Lowered Height (Standard Lift Pad)  5” (127 mm) G  Raised Height (Standard Lift Pad)  76” (1,930 mm) H  Raise Height With Adapters  85 1/2” (2,127 mm) I  Front Arm Reach  34”- 62” 864 mm – 1,575 mm) J  Rear Arm Reach  34” - 62” (864 mm – 1,575 mm)    Lifting Time  75 Seconds  Standard Power Requirements  230V - 60Hz - 1Ph - 20 amp 4 HP/2 kw motor  Shipping Weight  3,850 lb (1,750 kg)

Downloads

Flyer

General Warranty

 Click here for download
