Name: Coats 4T212SSR1 12,000 lb 2 Post Lift Symmetric (Red)
Brand: Coats
SKU: 4T212SSR1
Price: 9923 USD
Availability: InStock

Coats 4T212SSR1 12,000 lb 2 Post Lift Symmetric (Red)

Symmetrical Model: Easy access to approved lift points with 3 piece offset front & rear lifting arms for asymmetric and symmetric loading with reinforced carriage arm pin holes and plated gear style arm restraints.
Non Fatigue Cables & Pulleys: 3/8″ Non Fatigue Cables with 3.5″ Pulleys that are double the lifespan of plastic pulleys, making your lift last longer with less maintenance.
Tube Column Reinforcement: The 2.5” x 1.5” inner tube support lets heavier columns flex less under load.
US Made Power Units That Last: The energy efficient US Made Bucher 2HP power unit typically lasts the life of the lift with a single point lock release and rubber motor mounts to reduce motor noise.

	Model	12K Symmetric
	Capacity	12,000 lb/5.5 T
	ALI Certification	Yes
A	Overall Height	154 7/8” (3,934 mm)
A	Extended Height	N/A
B	Overall Width	145 1/8”(3,686 mm)
C	Width Between Columns	117 3/4”(2,991 mm)
D	Drive Thru Width	105 5/8”(2,682 mm)
E	Under Bar Clearance	149 1/2”(3,797 mm)
F	Lowered Height (standard pad fully in)	3-3/4”(102 mm)
G	Raised Height (standard pad fully out)	77”(1,958 mm)
H	Raised Height (with extensions)	86”(2,184 mm)
I	Front Arm Reach	36 1/4”- 61 5/8”(921 mm-1,565 mm)
J	Rear Arm Reach	36 1/4”- 61 5/8”(921 mm-1,565 mm)
	Lifting Time	75 seconds
	Standard Power Requirements	230 V, 1PH, 60Hz, 20A
