Product Overview
Coats APX90A Rim Clamp Tire Changer
Features
- Built-In Wheel Lift: The integrated wheel lift raises heavy assemblies to tabletop height, reducing operator effort, muscle strain, and the risk of wheel damage while improving control.
- Large Clamping Capacity: Large clamping capacity to externally clamp wheels up to 30″ or as small as 9″ in diameter to maximize service flexibility, without special adapters.
- Robo-Roller and Robo-Arm: The Robo-Roller comes installed, and it is used on the toughest of tires to help keep the following bead in the drop center. The Robo-Arm helper device applies pressure to create bead lock and hold top bead in drop center when mounting.
- Helper Devices: Multiple assist tools allow the operator to safely mount and demount difficult assemblies with ease.
- Integrated Wheel Lift: Lifts heavy assemblies, reducing both wheel damage risk and muscle strain for technicians.
- Large Clamping Capacity: Service wheels up to 30" without special adapters.
- Made in USA.
Specifications
| Model | APX90A |
| Wheel Handled | Steel, Alloy and High-Performance |
| Rim Diameter | 9" - 30" External |
| Maximum Tire Diameter | 44" Max |
| Maximum Rim Width | 16" Max |
| Bead Loosening System | Hand Actuated |
| Wheel Clamping System | 4 Clamps, Air Cylinder Operated |
| Mount/Demount Mechanism | Tilt-back with Automatic Safety Lock |
| Helper Devices | Robo-Arm, Robo-Roller, Horizontal Power Rollers, Duckhead Roller, Wheel Lift |
| Bead Seating Air Volume | 5.7 Gallons in Tower |
| Inflation Gauge | 0 - 60 psi |
| Air Supply Gauge | 0 - 300 psi |
| Air Drive System | 1.5 HP Air Motor, 110 - 175 psi, 15 scfm |
| Footprint | 53"w x 68"d x 88"h |
| Ship Weight | 1,510 lbs |
